Model # 7090-KIT Two Component Epoxy Adhesive Dispenser

Meritool PowerPush 7090-101 495ml Two Component Dispenser 450x45ml 10:1

Technical Specifications:
• Capacity: 16.7oz
• Ratio: 10:1 (450x45ml)
• Weight: 8.6 lbs (3.9 kg)
• Dimensions: 15.1 x 3.9 x 13.4” (384 x 100 x 341mm)
• Thrust: Factory set up to 1,800 lbs (8kN)
• Speed: Variable up to 6”/min (2.5mm/sec)
• Battery: 14.4V NiCd or 14.4V NiMH
• Charger: One hour quick charge 110V (240V model available)
• Battery Capacity: Up to 30 cartridge sets (material dependent)
• Dosing Limits: Variable from 3 to 32 seconds
• Top load – drop in cartridge holder



Cartridge Compatibility 10:1 (495ml):
• Nominal Size: 495ml
• L Dimension: 183mm
• A Capacity: 450ml
• B Capacity: 45ml
• Ratio: 10:1
• D1 Dimension: 20mm
• D2 Dimension: 65mm
• Strap Hook

Cartridge Compatibility 4:1 (400ml):
• Nominal Size: 400ml
• L Dimension: 183mm
• B Capacity: 85ml
• Ratio: 4:1
• D1 Dimension: 29mm
• D2 Dimension: 57mm
• Strap Hook

Cartridge Compatibility 2:1 (400ml):
• Nominal Size: 400ml
• L Dimension: 183mm
• A Capacity: 270ml
• B Capacity: 135ml
• Ratio: 2:1
• D1 Dimension: 36mm
• D2 Dimension: 51mm
• Strap Hook

Cartridge Compatibility 1:1 (400ml):
• Nominal Size: 400ml
• L Dimension: 183mm
• A Capacity: 200ml
• B Capacity: 200ml
• Ratio: 1:1
• D1 Dimension: 44mm
• D2 Dimension: 44mm
• Strap Hook

Posted in 200x200ml 1:1 (400ml), 270x135ml 2:1 (400ml), 340x85ml 4:1 (400ml), 450x45ml 10:1 (495ml), Model 7090-KIT | Comments Off on Model # 7090-KIT Two Component Epoxy Adhesive Dispenser

PowerPush 5026-600-14v 600ml Sausage Dispenser

PP5026-500



5026_600ml_back_500



Meritool has manufactured dispensers for the auto glass technician for 15 years. The POWERPUSH 5000 was developed, designed, assembled and tested in the USA.

The POWERPUSH 5000 is engineered to meet the rigorous requirements of the auto glass installation professional.

Our patented design is available in 10oz. cartridge, and 300, 400, and 600ml. sausage sizes.

PowerPush 5026-600-14v 600ml Sausage Dispenser

  • Includes PowerPush 5026 tool
  • 14.4 NiMH battery
  • 120v AC charger
Posted in 5026-600-14v, 600ml Sausage Dispenser, PowerPush 5000 Series | Comments Off on PowerPush 5026-600-14v 600ml Sausage Dispenser

PowerPush 5026-400-14v 400ml Sausage Dispenser

PP5026-500



5026_600ml_back_500



Meritool has manufactured dispensers for the auto glass technician for 15 years. The POWERPUSH 5000 was developed, designed, assembled and tested in the USA.

The POWERPUSH 5000 is engineered to meet the rigorous requirements of hte auto glass installation professional.

Our patented design is available in 10oz. cartridge, and 300, 400, and 600ml. sausage sizes.

PowerPush 5026-400-14v 400ml Sausage Dispenser

  • Includes PowerPush 5026 tool
  • 14.4 NiMH battery
  • 120v AC charger
Posted in 400ml Sausage Dispenser, 5026-400-14v, PowerPush 5000 Series | Comments Off on PowerPush 5026-400-14v 400ml Sausage Dispenser

PowerPush 5026-300-14v 300ml Sausage Dispenser

PP5026-500



5026_600ml_back_500



Meritool has manufactured dispensers for the auto glass technician for 15 years. The POWERPUSH 5000 was developed, designed, assembled and tested in the USA.

The POWERPUSH 5000 is engineered to meet the rigorous requirements of hte auto glass installation professional.

Our patented design is available in 10oz. cartridge, and 300, 400, and 600ml. sausage sizes.

PowerPush 5026-300-14v 300ml Sausage Dispenser

  • Includes PowerPush 5026 tool
  • 14.4 NiMH battery
  • 120v AC charger
Posted in 300ml Sausage Dispenser, 5026-300-14v, PowerPush 5000 Series | Comments Off on PowerPush 5026-300-14v 300ml Sausage Dispenser

PowerPush 5026-10-14v Cordless Dispenser


PP5026-500
5026_10oz_ISO_Black_W_PPLogo

Meritool has manufactured dispensers for the auto glass technician for 15 years. The POWERPUSH 5000 was developed, designed, assembled and tested in the USA.

The POWERPUSH 5000 is engineered to meet the rigorous requirements of hte auto glass installation professional.

Our patented design is available in 10oz. cartridge, and 300, 400, and 600ml. sausage sizes.

PowerPush 5026-10-14v 10oz Cartridge Dispenser

  • Includes PowerPush 5026 tool
  • 14.4 NiMH battery
  • 120v AC charger

Posted in 10oz standard cartridge, 5026-10-14v, PowerPush 5000 Series | Comments Off on PowerPush 5026-10-14v Cordless Dispenser

PowerPush 7500 50ML Industrial Adhesive Dispenser – (Black)

Applications:

Automotive Adhesives – Assembly, repair, Autobody
Industrial Adhesives
Electrical Adhesives
Marine Adhesives
Aerospace Adhesives

Features:

Complete Flexibility

Use almost any manufacturer’s material packaged in 50 ml dual component cartridges
Models are available for standard (rectangular flange) or new (rounded flange) cartridges, The PowerPush 7500 supports 1:1, 2:1, 3:2, and 4:1 mix rations in the 50ML capacity.

Speed Control

The PowerPush 7500 gives you complete control over the dispense speed of the highest viscosity materials, it can dispense materials up to 1 million cps at rates up to 1ml / second.

No Strain trigger

Using the Powerpush 7500 is easier on your hands as well, instead of squeezing the material with a manual dispenser the material flows with ease by depressing the trigger. This reduces operator strain and improves productivity by eliminating excessive hand strain.

True Portability

The PowerPush 7500 lets you work anywhere with the power of a NiMH rechargeable battery pack, it can also run off an A/C power adaptor.

Flow Control

The combination of effortless dispensing and Drip-Free operation makes it possible to accurately dispense a straight or curved bead where required.

Drip-Free knob

The Drip-Free feature significantly reduces or even eliminates oozing from the mix-tip upon release of the trigger.

Dimensions and Weight

1.75lbs
7.25 x 7.25 inches (without cartridge)



Battery Pack

The PowerPush 7500 includes a rechargeable, 7.2 volt nickel metal hydride (NiMH) battery. Since NiMH batteries have no “memory” build=up they can be charged whenever necessary without having to fully discharge the battery first.

Every PowerPush 7500 also ships with an A/c adaptor allowing the unit to be optionally powered from a standard 110V electrical outlet.  The A/C adaptor doubles as the battery charger, just leave the PowerPush 7500 plugged in overnight to fully charge the battery pack.



Configurations:

Model #
Cartridge Size
Cartridge Type
Mix Ratio
7500-11S-B
50ML (25 x 25)
S-Type
1:1
7500-21S-B
50ML (35 x 15)
S-Type
2:1
7500-32S-B
50ML (30 x 20)
S-Type
3:2
7500-11A-B
50ML (25×25)
A-Type
1:1
7500-21A-B
50ML (35×15)
A-Type
2:1
7500-41A-B
50ML (40 x 10)
A-Type
4:1
Posted in (50ML) 25ML x 25ML 1:1, (50ML) 30ML x 20ML 3:2, (50ML) 35ML x 15ML 2:1, (50ML) 40ML x 10ML 4:1, MODEL 7500-11A-B, MODEL 7500-11S-B, MODEL 7500-21A-B, MODEL 7500-21S-B, MODEL 7500-32S-B, MODEL 7500-41A-B, Uncategorized | Comments Off on PowerPush 7500 50ML Industrial Adhesive Dispenser – (Black)

Model # 7090-101 Two Component Epoxy Adhesive Dispenser

Meritool PowerPush 7090-101 495ml Two Component Dispenser 450x45ml 10:1

Technical Specifications:
• Capacity: 16.7oz
• Ratio: 10:1 (450x45ml)
• Weight: 8.6 lbs (3.9 kg)
• Dimensions: 15.1 x 3.9 x 13.4” (384 x 100 x 341mm)
• Thrust: Factory set up to 1,800 lbs (8kN)
• Speed: Variable up to 6”/min (2.5mm/sec)
• Battery: 14.4V NiCd or 14.4V NiMH
• Charger: One hour quick charge 110V (240V model available)
• Battery Capacity: Up to 30 cartridge sets (material dependent)
• Dosing Limits: Variable from 3 to 32 seconds
• Top load – drop in cartridge holder

Cartridge Compatibility:
• Nominal Size: 495ml
• L Dimension: 183mm
• A Capacity: 450ml
• B Capacity: 45ml
• Ratio: 10:1
• D1 Dimension: 20mm
• D2 Dimension: 65mm
• Strap Hook

Posted in 450x45ml 10:1 (495ml), Model 7090-101 | Comments Off on Model # 7090-101 Two Component Epoxy Adhesive Dispenser

Model # 7090-41 Two Component Epoxy Adhesive Dispenser

Meritool PowerPush 7090-41 400ML Two Component Dispenser 340x85ml 4:1

Technical Specifications:
• Capacity: 13.5oz
• Ratio: 4:1 (340x85ml)
• Weight: 8.6 lbs (3.9 kg)
• Dimensions: 15.1 x 3.9 x 13.4” (384 x 100 x 341mm)
• Thrust: Factory set up to 1,800 lbs (8kN)
• Speed: Variable up to 6”/min (2.5mm/sec)
• Battery: 14.4V NiCd or 14.4V NiMH
• Charger: One hour quick charge 110V (240V model available)
• Battery Capacity: Up to 30 cartridge sets (material dependent)
• Dosing Limits: Variable from 3 to 32 seconds
• Top load – drop in cartridge holder

Cartridge Compatibility:
• Nominal Size: 400ml
• L Dimension: 183mm
• A Capacity: 340ml
• B Capacity: 85ml
• Ratio: 4:1
• D1 Dimension: 29mm
• D2 Dimension: 57mm
• Strap Hook

Posted in 340x85ml 4:1 (400ml), Model 7090-41 | Comments Off on Model # 7090-41 Two Component Epoxy Adhesive Dispenser

Model # 7090-21 Two Component Epoxy Adhesive Dispenser

Meritool PowerPush 7090-21 400ml Two Component Dispenser 270x135ml 1:1

Technical Specifications:
• Capacity: 13.5oz
• Ratio: 2:1 (270x135ml)
• Weight: 8.6 lbs (3.9 kg)
• Dimensions: 15.1 x 3.9 x 13.4” (384 x 100 x 341mm)
• Thrust: Factory set up to 1,800 lbs (8kN)
• Speed: Variable up to 6”/min (2.5mm/sec)
• Battery: 14.4V NiCd or 14.4V NiMH
• Charger: One hour quick charge 110V (240V model available)
• Battery Capacity: Up to 30 cartridge sets (material dependent)
• Dosing Limits: Variable from 3 to 32 seconds
• Top load – drop in cartridge holder

Cartridge Compatibility:
• Nominal Size: 400ml
• L Dimension: 183mm
• A Capacity: 270ml
• B Capacity: 135ml
• Ratio: 2:1
• D1 Dimension: 36mm
• D2 Dimension: 51mm
• Strap Hook

Posted in 270x135ml 2:1 (400ml), Model 7090-21 | Comments Off on Model # 7090-21 Two Component Epoxy Adhesive Dispenser

Model # 7090-11 Two Component Epoxy Adhesive Dispenser

Meritool PowerPush 7090-11 400ml Two Component Dispenser 200x200ml 1:!

Technical Specifications:
• Capacity: 13.5oz
• Ratio: 1:1 (200x200ml)
• Weight: 8.6 lbs (3.9 kg)
• Dimensions: 15.1 x 3.9 x 13.4” (384 x 100 x 341mm)
• Thrust: Factory set up to 1,800 lbs (8kN)
• Speed: Variable up to 6”/min (2.5mm/sec)
• Battery: 14.4V NiCd or 14.4V NiMH
• Charger: One hour quick charge 110V (240V model available)
• Battery Capacity: Up to 30 cartridge sets (material dependent)
• Dosing Limits: Variable from 3 to 32 seconds
• Top load – drop in cartridge holder

Cartridge Compatibility:
• Nominal Size: 400ml
• L Dimension: 183mm
• A Capacity: 200ml
• B Capacity: 200ml
• Ratio: 1:1
• D1 Dimension: 44mm
• D2 Dimension: 44mm
• Strap Hook

Posted in 200x200ml 1:1 (400ml), Model 7090-11 | Comments Off on Model # 7090-11 Two Component Epoxy Adhesive Dispenser
